| PERFORMANCE |
| Processor |
Intel® Core™ i9-12900, 16C (8P + 8E) / 24T, P-core 2.4 / 5.0GHz, E-core 1.8 / 3.8GHz, 30MB
|
| Processor Sockets |
1x FCLGA1700
|
| Integrated Graphics |
Integrated Intel® UHD Graphics 770
|
| Discrete Graphics |
1x NVIDIA® T400 4GB
|
| Chipset |
Intel® W680 Chipset
|
| Memory |
16GB UDIMM DDR5-4800 Non-ECC
|
| Memory Slots |
Four DDR5 UDIMM slots, dual-channel capable
|
| Max Memory |
Up to 128GB (4x 32GB DDR5 UDIMM)
|
| M.2 SSD RAID Controller |
Onboard Intel® RSTe PCIe®
|
| M.2 SSD Drive |
1x 512GB SSD M.2 2280 PCIe® 4.0x4 Performance NVMe® Opal
|
| HDD Controller |
Onboard Intel® RST SATA RAID
|
| SATA/SAS Drive |
None
|
| Storage Support |
Up to 2x 3.5" SATA HDD or 4x 2.5" SATA HDD; also supports up to 3x M.2 SSD (2 by onboard, 1 by M.2 to PCIe® adapter ) • 3.5" HDD up to 4TB each • 2.5" HDD up to 1TB each • Onboard M.2 SSD up to 4TB each • M.2 SSD by M.2 to PCIe adapter up to 2TB
|
| Optical |
None
|
| Audio Chip |
High Definition (HD) Audio, Realtek® ALC897Q-CG codec
|
| Power Supply |
500W Platinum Fixed
|
| DESIGN |
| Keyboard |
USB Calliope Keyboard, Black, English
|
| Mouse |
USB Calliope Mouse, Black
|
| Expansion Slots |
- One PCIe® 4.0 x16
- One PCIe® 4.0 x16 (x4 lanes)
- Two PCIe® 3.0 x1 (open ended)
|
| M.2 Slots |
- Up to 3x M.2 SSD: • 2 via onboard M.2 PCIe® Gen 4 slots • 1 via Single M.2 to PCIe adapter, PCIe Gen 3
- One M.2 slot for WiFi
|
| Bays |
- 1x 3.5" disk bay (standard)
- 1x 3.5" disk bay (optional)
- 2x 2.5" disk bay (optional)
|
| Dimensions (WxDxH) |
170 x 315.4 x 376 mm (6.7 x 12.4 x 14.8 inches)
|
| Weight |
9.67 kg (21.32 lbs, maximum configuration)
|
| CONNECTIVITY |
| Onboard Ethernet |
Intel® I219-LM, 1x GbE RJ-45
|
| Optional Ethernet |
None
|
| WLAN + Bluetooth |
None
|
| Card Reader |
None
|
| Front Ports |
- 2x USB 3.2 Gen 1
- 2x USB 3.2 Gen 2
- 1x USB-C® 3.2 Gen 2
- 1x headphone / microphone combo jack (3.5mm)
- 1x microphone (3.5mm)
|
| Rear Ports |
- 1x HDMI® 2.1 TMDS
- 2x DisplayPort™ 1.4
- 4x USB 3.2 Gen 1 (one supports Smart Power On)
- 1x Ethernet (RJ-45)
- 1x line-out (3.5mm)
|
| Optional Rear Ports (configured) |
None
|
| SECURITY & PRIVACY |
| Security Chip |
Discrete TPM 2.0, TCG certified
|
| Physical Locks |
- Kensington® Security Slot™, 3 x 7 mm
- Padlock Loop
|
| Cover Lock |
None
|
| Cable Lock |
None
|
| Chassis Intrusion Switch |
None
|
| MANAGEABILITY |
| System Management |
Intel® vPro® Enterprise with Intel AMT 16
|
| SERVICE |
| Base Warranty |
1-year, Onsite
|
| Included Upgrade |
3Y Premier Support Upgrade from 1Y Onsite (5WS0T36199)
|
| Green Certifications |
- EPEAT™ Gold Registered
- ENERGY STAR® 8.0
- ErP Lot 3
- TCO Certified 9.0
- RoHS compliant
|
| ISV Certifications |
|
| Mil-Spec Test |
MIL-STD-810H military test passed
|
| SOFTWARE |
| Operating System |
None
|
| Bundled Software |
None
|
